Product Description
unctions:
1. Automatic deliver materials include
cartridges, sealant, plungers
3. Automatic Counter
4. Breakdown Warning and Protecting Function
Configuration
Hydraulic extractor,
Hydraulic pressure station,
Delivering bottle part,
Clamping bottle part,
Measuring part,
Filling part,
Leak proofing part,
Delivering lid part,
Testing part,
Screwing lid part,
Controlling part,
Praying & delivering part.
Ink-jet printer(selected).
|
TYPES Specification |
WT0006 |
|
Double Heads Hydraulic
type
Filling and capping machine |
|
|
Power Capacity |
3-50Hz
380V |
|
Convey pipe |
Rubber
pipe Dg50 |
|
Loading pipe
Diameter and QTY |
Φ32mm for plastic tube, 2 filling pipes |
|
Plate Diameter |
Φ570mm |
|
Drum Size: |
200L |
|
Pump Type |
Hydraulic Pump Station YG-4KB-E, Hydraulic Pump
Type CBN-316 |
|
Recommended
rubber |
Fluid sealant of silicone, electronic glue, auto fluid sealant, AB
sealant, architectural fluid sealant, polyurethane, lubricating grease. |
|
Oilcan pressure |
Max 15mpa |
|
Motor power |
6kw |
|
Control Valve |
Hydraulic Valve |
|
Quantity Control
Mode |
Automatic |
|
Sealing
Set |
Two Plastic tube drillers
|
|
Operating type |
Automatic |
|
Packing Container |
Plastic
cartridge |
|
Loading and plugging station |
two for each station |
|
Filling Speed |
50-60pcs/minute |
|
Loading range |
50-450g±0.5g |
|
Size and weight |
Filling and closing machine 3300X1100X1500mm |
|
Note |
Not including air compressor,
which should be 3kw, 0.9mpa, 0.3m3/min. |
1、 Delivery:
50 working days
2、 Payment
term: 50% in advance and balance before shipment
3、 Warranty:
We offer one year and
a half warranty and all life maintain.
4、 Packing: The
machine will be packed into polywooden cases
